Category 3 Multipair Cables

Posted at: Offers to Sell and Export | Posted on: Thu 06 Aug, 2009 2:59 am |

category 3 multipair cables
Products Photos CatalogCategory Multipair Photos Catalog



◎ Applications:

10Base-T, 100Base-T4

◎ Standards:


Iso/iec11801, ansi/tia/eia-568-b



Working Frequency:

1-16MHz

◎ Technical Parameters:

☆ Characteristic Impedance: 10015Ω

☆ Nominal Velocity of Propagation (NVP): 69%

☆ Maximum DC Resistance: 9.38Ω/100m

☆ Maximum Resistance Unbalance: 5%

☆ Maximum Propagation Delay Skew: 30 ns/100m

☆ Maximum Propagation Delay: 536 ns/100m@100 MHz

☆ Minimum Bending radius: 10 x Overall Diameter

☆ Voltage Rating: 60V rms

☆ Maximum Pulling load: 80N

☆ Working Temperature: -20℃ ~ +60℃

☆ Storage Temperature: -5℃ ~ +50℃

☆ Flame Retardancy: UL 1581 (CM Jacket); UL 1666 (CMR Jacket); UL 910 (CMP Jacket); IEC 60332-1 (FRPVC

& LSZH Jacket); IEC 60332-1 and IEC 60332-3C (LSFROH Jacket)

◎ Product Highlights:

☆ Provide excellent bandwidth beyond 600 MHz.

☆ Support 10 Gigabit Ethernet application.

☆ Meet the strict flame retardancy and environmental requirements in Europe and US.

☆ Different jacket materials available for choice.



Company Contact:

No member photo
Contact Name: Rose
Company Name: Addison Cabling System
Email: Email
Tel: 85221185380 or 852-21171256
Fax: 852-21161041
Street Address: Unit B, 22/F., CMA Building,
64 Connaught Road Central, Hong Kong
Website: http://www.addison-tech.com
Member name: addisoncable
Country: Hong Kong-HK Hong Kong
Member Since: 05 August 2009
Total Leads: 6 addisoncable Import Export Business Leads
Business focus: Addison Cabling System Fiber Optic Cable, Coaxial Cable, Fire Performance Standard
