Conventional Fire Control Panel Alarm System

Posted at: Offers to Sell and Export | Posted on: Mon 26 Jul, 2010 7:08 am | Product Category: Fire alarm control panel [5]

conventional fire control panel alarm system
Products Photos CatalogConventional Fire Photos Catalog



Name: Fire Alarm Control Panel

Model: VS-CK1004/1008/1016


1000 Series Conventional Fire Alarm Control

Panel

Main Feature

4, 8 or 16 zones, 2 Sound Output Conventional Fire Alarm Control Panel.

Sixteen Style B (Class B) Initiating Device Circuits (IDCs) .

All zones accept two-wire smoke detectors and any normally-open contact devices.

Four built-in, Style Y (Class B) Notification Appliance (Signal) Circuits (NACs).

Alarm, Trouble and Supervisory, Form-C relays standard.

24-volt operation.

Resettable four-wire smoke detector power @ 500 mA.

Non-resettable power @ 500 mA.

One-man walk-test programmable for silent or audible test. * Disable/Enable control per IDC.

Reverse polarity protection.

Technical Parameter

Ac power

220 VAC, 50 Hz, 2.0 amps.

Wire size: minimum 14 AWG (2.0 mm˛) with 600-volt insulation.

Battery

Sealed lead-acid batteries only.

Maximum charging circuit: 27.6VDC @ 0.8 amp for

normal flat charge.

Maximum battery charger capacity: 18AH battery.

Note

two 4AH batteries can be housed in the cabinet. Larger

batteries require a separate battery box.

Total 24 V system power: 3.0 amps.

Notification appliance (signal) power: 2.5 amps.

Maximum current per NAC: 1.25 amps (expandable to 2.5amps).

Maximum battery charging capability: 18 AH.
