■ Design Speed: 120m/min.
■ Expiry width: 1400mm-2000mm.
■ Flute profiles:
A, B, C, E etc. available discretionarily.
■ Drive decelerate box adopts oiliness lubricate. light noise, adopt small gimbal transmission. separate power.
■ Lift-lower of upper corrugating roller, pressure roller and glue roller are completed by pneumatic control.
■ Cardboard transmitting method adopts vacuum adsorb equipment, with wind control. keep flute profiles stable of the lower-roller in the condition of running up.
■ Axletree of corrugated and pressure roller adopts high temperature resistant lube.
■ Glue parts auto supply glue circularly.
■ The upper-lower corrugating roller are made of high quality chrome 48CrMo molybdenum alloy steel and heat-treatment. The rigidity is HRC55-58°, the surface are whetted.
■ The glue part surface are treated by special mesh snicked and chromeplated.
■ Adopt Electromotion or handle separate glue equipment.
■ Glue part can be running independently or non-independently while stopped. Adopt main motor frequency conversion control.
