Gsm Home Control Appliances In China

Posted at: Offers to Sell and Export | Posted on: Wed 05 May, 2010 3:44 pm |

gsm home control appliances
Products Photos CatalogGsm Home Control Photos Catalog



Patrol Hawk Security is the trusted name in wireless home security. Many homeowners today live in density



housing and strata blocks, which limits hardwired home security. Whether you rent, lease or in temporary housing, the Patrol Hawk Wireless Home Security Package from Patrol Hawk provides the perfect solution in home security.

Name: GSM Controller SMS DTU-5010

The GSM Controller DTU5010 is a universal GSM dialer and controller as well as a GSM Remote Control and Alarm Unit. it provides 4 relay drivable outputs(12V-24V), 4 inputs and RS232 Serial Port. It allows you to monitor and control an alarm or remote stations or equipments or machines by SMS(Short Message Service) Or transport data between user and PLC. Another, it can transmit data from apparatus (thermometer, humidity meter, electric meter, flowmeter) to user or monitoring center by SMS(GSM DTU).

(The different from the GSM Controller DTU5010 is the GSM Controller DTU5011 with 8 I/O Ports, 4AD inputs, Microphone and Speaker . The GSM Controller RTU5010 with 4 I/O ports, without AD inputs, Microphone and Speaker. The other functions are the same.)

The GSM Controller DTU5010 can be used as:

A switch with SMS remote control. SMS texts for switching particular terminals on/off are configurable.

A timer-switch which can be activated automatically. It can be used as preset when the GSM Controller need work and when it needn‘t work. The user can set 6 appointed time.

A relay with dialling-in remote control. Up to 10 tel. numbers can be authorized for it. Because calls are not answered dialling-in control within GSM is free of charge. (it only checks the caller’s number and - if the number is authorized - responds with relay activation.) This can be used for parking latch control, gsm gate opener, remote control machine, etc.

An automation system. Each input can link to output actions, this is very useful when the temperature upto appointed value, need switch on the air-conditioning immediately, or when water overflow and need switch on the dryer, or when somebody broken into the door or windows need to start the CCTV and Siren.

A SMS reporter. The 4 Inputs activations or deactivations can be reported by SMS and optionally confirmed by phone calls. Each input can have its own message texts and the message can be programmed by users.

A data transporter (GSM DTU, GSM M2M ). The RS232 serial port can be used as remotely collecting the data from PLC or other equipments then send to user and monitoring center, also, it can accept the users SMS commands then transport the commands to the PLC directly.

A GSM Alarm system. the user can arm it or disarm it by SMS. also, the first input can be used as Arm or Disarm button, the other 3 inputs can be used as door sensor, motion sensor, temperature sensor, water overflow sensor, AC power failure sensor, oil pressure sensors, etc.

A GSM Remote Termials (GSM RTU). It can work with the supervisioning center, in the supervisioning center, the own can remote monitoring and control the remotely terminals by GSM Network.This is very useful to street light control, wellhead control, BTS environment monitoring, power transmission system monitoring and other applications.

What Applications does the GSM Controller DTU5010 suitable for?

1. Security Alarm System applications;

2. Supervision and monitoring alarm systems

3. Automatic monitoring system;

4. Vending Machines;

5. Pumping Stations;

6. Buildings and Real Estate;

7. Weather Stations;

8. River Monitoring and Flood Control;

9. Oil and gas pipelines;

10. Corrosion protection

11. Valve controls;

12. Wellheads;

Mainly Features of the GSM Controller DTU5010:

◆ 4 relay drivable outputs(12V-24V), Any relay can be switched on by sending a SMS or call to the unit;

◆4 Alarm logic inputs for SMS reporting and dialing (the inputs react to a connection or disconnection to or from a common GND terminal);

◆ Bidirectional data transmission, this is very useful to connect PLC equipments;

◆ Can read logic input status by SMS;

◆ Up to10 different mobile phones numbers can be pre-set in the system;

◆ Password protected, prevents unauthorised use;

◆ Each logic input can be assigned to one or more output relays;

◆ Can be set up and programmed from any GSM phone and PC;

◆ An arm or disarm button is optional for the user;

◆ Timer function, can be programmed when send back the report or when switch on the output relays.

◆ Time stamped alarm messages.

◆ Based on GSM Network.

Standard Package includes:

GSM Controller X 1

Power supply adapter X 1 (12V 1.5A 1)

Serial cable for communication X 1 (RS232)

CD (Pc programmer tool) X 1

GSM Antenna X 1

Optional Accessories:

Water Overflow Level Sensor, Oil Overflow Level Sensor, Water Leak Sensor, Temperature Sensor, Door Sensor, PIR Motion Sensor, Smoke Sensor, Gas Leak Sensor, Glass Break Sensor, Shock Sensor, Power failure sensor, etc.
