High Pressure Reactor

GS Series

Adopting end face terrae earth permanent magnetic coupling drive, GS series high pressure kettle has characteristics of static steal and no leakage. The body of kettle adopts 1Cr18Ni9Ti stainless steel and it can manufacture titanium material (TA2), Teflon lining and nickel (Ni6) according to different medium. The stirring shaft adopts anti cauterization stainless steel shaft, which is suitable for stirring of high rotated speed and low viscidity materials. The method of discharging has two methods: up mouth for discharging and low mouth for discharging that can offer user when order. This series product has many good characteristics such as stable operation, low noise and convenient operation and so on, which is the excellent equipment for taking kinds of chemical examinations in lab.


Specs and Technical Parameter of GS Series Autoclave
Type GS-0.1 GS-0.25 GS-0.5 GS-1 GS-2 GS-3
Nominal Cubage L 0.1 0.25 0.5 1 2 3
Working Pressure Mpa 10-15 10-15 10-15 10-20 10-20 10-20
Working Temperature ¡æ 300 300 300 300 300 300
Stirring Rotated Speed r/min 0-1500 0-1500 0-1500 0-1500 0-1500 0-1500
Motor Power W 40 40 80 80 80 200
Heating Power KW 0.8 0.8 1 1.5 2 3
Control It equips automatic temperature adjuster with temperature precision ¡À1¡æ. It has rotated speed display and timing speed function; the heating power can be adjustable that can carry out the aim of automatic adjusting temperature.
