Laser Machine Ys-eld2000b

Posted at: Offers to Sell and Export | Posted on: Wed 09 Dec, 2009 6:48 am |
laser machine ys eld2000b
Products Photos CatalogLaser Machine Eld2000b Photos Catalog

Model Number: YS-ELD2000B

With the technology of diode pump, air cooler, engraving speed of 2000dot/sec

and max engraving size at ellipse170*140*100mm, ELD2000B can finish engraving within 2mins for a 3D model of 180, 000dots, is quite suitable to run in the shopping mall or tourism place to make 3D and 2D image crystal gift on spot, receive big orders and fulfill most of the requirement from the customer.


(1) Laser Medium: Diode (DPSSL-Q Switch)

(2) Laser Wavelength: 532nm

(3) Maximum Engraving frequency: 2.5 KHZ

(4) Laser Source: 1

(5) Resolution: 800 dpi

(6) Engraving Dimension: Max Ellipse170*140*100mm

(7) Engraving speed (average: 120, 000dots/min (2000dots/sec)

(8) Input Power standard: 220V/ 110V, 50HZ

(9) Working Consumption of Electricity: 0.6KW

(10) Dimension of The Mainframe:

L570mm*W780mm*H1000mm (big)

L760mm*W560mm*H560mm (small)

(11) Weight: 110KG(big), 75kg (small)

(12) Cooling system: air cooler

(13) Appearance: two options

(14) Warranty for the laser diode: 8000hrs (not exceed one year)

Company Contact:

shining3d photo
Contact Name: Jocelyn Zhu
Company Name: Hangzhou Shining 3d Tech Co., Ltd
Email: Email
Tel: 86-0571-82999131
Fax: 86-0571-82999539
Street Address: 18th Floor, Block A,
Huarui Center, No.66, Jianshe Yi
Road, Xiaoshan, Hangzhou, China
Website: http://www.shining3d.com
Member name: shining3d
Country: China-CN China
Member Since: 09 December 2009
Total Leads: 19 shining3d Import Export Business Leads
Business focus: Laser Engraving Machine, 3d Camera, 3d Scanner, Cav, Re, Rd
