Pipe Base Screen

Posted at: Offers to Sell and Export | Posted on: Mon 06 Dec, 2010 9:30 am |
pipe base screen
Products Photos CatalogPipe Base Screen Photos Catalog

This is bob from haixing wedge wire company.We are a manufacturer of pipe base screen in china.The base

pipe, casing or tubing, is selected to API specifications by size, grade and weight for each of your required applications.Our slip-on type of pipe base screen is manufactured from two components: the base pipe and the slip-on screen.The base pipe will be perforated with a series of holes drilled to a pre-determined quantity and pattern, to carefully balance flow-capacity at each end for both down-hole handling.The holes are then debarred and the joint cleaned, inspected and treated to give the base pipe a long shelf life.Our slip-on screens are manufactured to very exact diameter, length gauge and strength tolerances. This is done by selecting the required profile wire and support rod, which determine the flow-capacity and strength of the slip-on screen. For each gauge opening in the screen we select a slightly greater than that of the perforated base pipe. This will give the pipe base screen optimum flow-capacity at minimum pressure drop across the screen.If you have any enquiry of pipe base screen, please feel free to contact us.

Company Contact:

No member photo
Contact Name: Bob Hu
Company Name: Haixing Wedge Wire Company
Email: Email
Tel: 86-318-7086212 or 86-318-7086816
Fax: 86-318-7086810
Street Address: No.2589 West Shengli Road,
Hengshui, Hebei, China
Website: http://www.wedgewires.com
Member name: haixingbob
Country: China-CN China
Member Since: 06 December 2010
Total Leads: 17 haixingbob Import Export Business Leads
Business focus: Wedge Wire Screen, Johsnon Well Screen, Sand Control Screen, Wire Wrap Screen, Pipe Base Screen, Stainless Steel Well Point Screen
