1.Adopted to color touch screen and high accuracy output
PLC control, bag making, measuring, filling, sealing, date printing, product output in one operation.
2.The control of pneumatic and power is independent, noise is low, working is stable.
3.Adopted to vocuum drawing film, less pulling resistance, bag is formed in better appearance.
4.Double servo control, high accuracy position with specification size.
5.Adopted to external film releasing mechanism,simple and easy to install the packaging film.
6.Adjustment of bag deviation just needed to be played on the touch screen, easy to operate.
7.Close down machine framework, defending powder into inside of the machine.
Scope of Application:
Suitable for the packing of puffy food, peanut, coffee, small biscuit, candy, melon seeds, chips, nutlet, jelly, preserved fruit etc
Bag size: L (80-400) * W (80-250) mm
Packing speed: 5-50 bags/min
Measuring range: max 3000 ml
Max width of film roll: ≤520 mm
Air consumption: 0.65 mpa
Gas consumption: 0.4 m3/min
Power requirement: 220 V, 50 HZ
Machine size: L 1150 * W 1795 * H 11650 mm
Machine weight: 600KG
