3150 Ton Open Die Forging Hydraulic Press

Posted at: Offers to Sell and Export | Posted on: Fri 10 Aug, 2012 3:48 am |

3150 ton open die forging hydraulic press
Products Photos Catalog3150 Ton Open Die Photos Catalog



Capacity kn 31500

WORKING OIL PRESSURE MPa 25


DAYLIGHT mm 4000

STROKE mm 2000

DISTANCE BETWEEN COLUMNS

CENTER mm 3500×1900

DIAMETER OF COLUMN mm 500

DIMENSION OF SHIFTING TABLE mm 6000×2000×350

STROKE OF SHIFTING TABLE mm 4000

Capacity of return kn 2000

Working positions of shifting table 3

ECCENTRICITY DIMENSION OF FORGING mm 150×120

Grade numbers of capacity 2

First capacity kn 15000

Secondly capacity kn 31500

Thirdly capacity kn

PRESSING SPEED AT APPROACH mm/s 300

PRESSING SPEED AT FIRST CAPACITY mm/s 137

PRESSING SPEED AT SECONDLY CAPACITY mm/s 55

PRESSING SPEED AT THIRDLY CAPACITY mm/s

RETURN SPEED mm/s 300

SPEED OF SHIFTING TABLE mm/s 200

ACCURACY OF SHIFTING TABLE MOVING mm ±0.5

DEGREE OF FORGING times/m 45

Carrying capacity of shifting table t 50

SHIFTING TABLE HEIGHT ABOVE FLOOR LEVEL mm 0

Total power kw 2200

Weight of press(total) t 440

OVERALL HEIGHT ABOVE FLOOR LEVEL mm 11000
