Abm K Span Roll Forming Machine For No Girder Construction

Posted at: Offers to Sell and Export | Posted on: Friday 18 June 2010 5:02 am | Poster last visit: Friday 24 February 2012 |

Product Photo:

abm k span roll forming machine girder construction

Similar Products Catalog:
Products Photos Catalog Abm Span Roll Forming Photos Catalog

Product Description:

ABM K Span Roll Forming Machine For No Girder Construction:

ALLSTAR MACHINERY:Large Span Forming Machine,


K Span Forming Machine, Super Span Forming Machine

Main Technical Specification of UBM Roll Forming Machine

Size: 11000mm × 2300mm × 2300mm

Total Weight: about 20000KG

Main Motor Power: 19.0KW forming power is 7.5kw; bending power is 5.5kw; cutting power is 3.0kw; conical power is 3.0kw

Material of rollers: 45# steel, quenched HRC 58-62

Material of roller shafts: 45# steel, quenched HRC 58-62

Material of cutting blade: Cr12 steel

Step of rollers: 13 steps

Number of Roller: about 350 pieces

Feeding Width: 914mm

Effective Width: 610mm

Thickness of the coil: 0.6-1.5mm

Control System: automatic

Controlling the straight forming and arching with computer

Gear/Sprocket driving: 13 forming stations

Passive decoiler: Double

Max. Capacity: 5000kgs suitable for trailer carrying

Electric Standard : 380V / 50 HZ / 3 PHASE

Type of cutting: Roll-formed and length-set cutting



Company Contact:

No member photo
Contact Name: Sales
Company Name: Shanghai Allstar Industrial Co., Ltd
Email: Email
Tel: 86-21-67353838
Fax: 86-21-57350108
Street Address: No.16 XinShun Road,
XinNong Industrial Zone, JinShan District,
Shanghai, China
Website: http://www.ranger-sh.com/
Member name: ShanghaiAllstar
Country: China-CN China
Member Since: 09 April 2010
Total Leads: 151 ShanghaiAllstar Import Export Business Leads
Business focus: Roll Forming Machine, Cold Roll Former, Roll Forming Machine Design, Metal Sheet Roll Former, Trapezoidal Sheet Forming Machine, Trim Deck Forming
