Automatical Decoiler

Posted at: Offers to Sell and Export | Posted on: Friday 15 July 2016 9:48 am | Poster last visit: Monday 31 October 2016 |

Product Category: Main » Tools and General Machinery » Hydraulic machinery and equipment » Hydraulic tools » Hydraulic shears » Automatical Decoiler


Product Photo:

automatical decoiler

Similar Products Catalog:
Products Photos Catalog Automatical Decoiler Photos Catalog

Product Description:

Automatical decoiler

A) Main specifications:


 Active uncoiling, hydraulic to expand



Weight capacity: 5/7/10/15 Ton

 Width of coil: 1500mm Max.

 Inner diameter: 508-610mm

 Outer diameter: 1300mm

 Material of main shaft: 40Cr

 Outline dimentision: about 3110x1650x1780mm

 Hydraulic motor power: 2.5KW

 Pneumatic damp pressing arm

 Uncoiling speed: 0-15m/min

 Capacity of hydraulic station: 40L

 Hydraulic system pressure: 6.3Mpa

 Coil car stoke: 2.5m

 Pressure of hydraulic system:6.3Mpa

 Weight of coil beared by car: 10Ton



Company Contact:

WuxiTechwellMachinery photo
Contact Name: Joanna
Company Name: Wuxi Techwell Machinery Co., Ltd
Email: Email
Tel: 86-0510-83133431
Fax: 86-0510-83133431
Street Address: Chong An District
Wuxi, Jiangsu Province 214000
China
Member name: WuxiTechwellMachinery
Country: China-CN China
Member Since: 15 July 2016
Total Leads: 40 WuxiTechwellMachinery Import Export Business Leads
Business focus: Cold Roll Forming Machines, Insulated Sandwich Panels Machines, Slitting Cutting Machines
