Part number fsbb20ch60f
BRAND Fairchild Semiconductor [Fairchild]
Date code 11+
PRICE Email us
Summary smart power module, low power inverter-driven application, SPM27CA
Description as follow:
The FSBB20CH60F is a smart power module. It is an advanced smart power module (SPM) that Fairchild has newly developed and designed to provide very compactand high performance ac motor drives mainly targeting low power inverter-driven application like air conditioner and washingmachine. It combines optimized circuit protection and drivematched to low-loss IGBTs. System reliability is furtherenhanced by the integrated under-voltage lock-out and shortcircuitprotection. The high speed built-in HVIC provides optocoupler-less single-supply IGBT gate driving capability that furtherreduce the overall size of the inverter system design. Eachphase current of inverter can be monitored separately due tothe divided negative dc terminals.
Absolute maximum ratings: (1)Supply Voltage, Applied between P- NU, NV, NW, VPN: 450V; (2)Supply Voltage (Surge) Applied between P- NU, NV, NW, VPN(Surge): 500V; (3)Collector-emitter Voltage, VCES: 600V; (4)Each IGBT Collector Current, TC = 25℃, ±IC: 20A; (5)Each IGBT Collector Current (Peak), TC = 25℃, Under 1ms Pulse Width, ±ICP: 40A; (6)Collector Dissipation, TC = 25℃ per One Chip, PC: 61W; (7)Operating Junction Temperature, TJ: -20 to 125℃.
Features: (1)UL Certified No.E209204(SPM27-CA package); (2)Very low thermal resistance due to using DBC; (3)600V-20A 3-phase IGBT inverter bridge including control ICs for gate driving and protection; (4)Divided negative dc-link terminals for inverter current sensing applications; (5)Single-grounded power supply due to built-in HVIC; (6)Isolation rating of 2500Vrms/min.
