Metal Cascade Ring

Posted at: Offers to Sell and Export | Posted on: Fri 30 Nov, 2018 2:26 am | Product Category: Structured packing [24]

metal cascade ring
Products Photos CatalogMetal Cascade Ring Photos Catalog



Metal Cascade Ring

Metal Tower Packing


Specification:

The Parameters of Metal Ladder Ring (CMR)

Model

SizeD*H*δ/mm No. Per Volumen/m3 Specific  Aream2/m3 Void Volume% Drying Packing Factorm-1

Dg16 16X8X0.4 290000 240 0.92 300

Dg25 25X12.5X0.5 97160 220 0.93 273.5

Dg38 38X19X0.6 31890 154.3 0.94 185.8

Dg50 50X25X0.8 12600 109.2 0.95 127.4

Dg76 76X38X1.0 3420 90 0.925 112.4

Advantages:

Ladder Ring(Cascade mini ring),  draws the benefits of Rasching ring and Pall ring,  the Height-diameter ratio is 1:2, Because of increasing the Cone flanging , ladder ring can reduce the resistance of gas and the intensity of packing,  as well as gas-liquid contact area.

Application: Desulfurization of amine, synthesis of amine decarbonization, common decompression, such as methanol separation, separation of organic acids and so on.

Materials: STEEL, CARBON STEEL, etc
