Steel Cord Conveyor Belt
Posted at: Offers to Sell and Export | Posted on: Monday 25 January 2021 8:08 am | Poster last visit: Monday 25 January 2021 |
Product Category: Main
» Material Handling and Conditioning and Storage Machinery and their Accessories and Supplies
» Material handling machinery and equipment
» Conveyors and accessories
» Belt conveyors
» Steel Cord Conveyor Belt
Product Description:
Steel Cord Conveyor Belt Wire rope core conveyor belt conveyor belt manufacturers in china rubber
belting for sale
acid and alkali resistant conveyor belt DESCRIPTION
Belt type ST630 ST800 ST1000 ST1250 ST1600 ST2000 ST2500 ST2800 ST3150 ST3500 ST4000 ST4500 ST5000 ST5400
Min. tensile strength (N/mm) 630 800 1000 1250 1600 2000 2500 2800 3150 3500 4000 4500 5000 5400
Max. diameter of steel cord (mm) 3.0 3.5 4.0 4.5 5.0 6.0 7.2 7.2 8.1 8.6 8.9 9.7 10.9 11.3
Steel cord pitch (mm) 10.0±1.5 10.0±1.5 12.0±1.5 12.0±1.5 12.0±1.5 12.0±1.5 15.0±1.5 13.5±1.5 15.0±1.5 15.0±1.5 15.0±1.5 16.0±1.5 17.0±1.5 17.0±1.5
Top/Bottom cover thickness (mm) 4.0 4.0 4.0 4.0 4.0 4.0 5.0 5.0 5.5 6.0 6.5 7.0 7.5 8.0
Belt width Number of steel cord
St630 St800 St1000 St1250 St1600 St2000 St2500 St3150 St3500 St4000 St4500 St5000 St5400
800 75 75 63 63 63 63 50 50 50
1000 95 95 79 79 79 79 64 64 64 64 59 55 55
1200 113 113 94 94 94 94 76 76 77 77 71 66 66
1400 133 133 111 111 111 111 89 99 90 90 84 78 78
1600 151 171 126 126 126 101 101 101 104 104 96 90 90
1800 143 143 143 143 114 114 117 117 109 102 102
2000 159 159 159 159 128 128 130 130 120 113 113
2200 176 141 141 144 144 134 125 125
2400 193 155 155 157 157 146 137 137
2600 209 168 168 170 170 159 149 149
2800 171 161 161
Note: not applicable (not available) due to availability.
Wire Rope Core Conveyor Belt Features: high tensile strength, good impact resistance, long life, small use elongation, good groove, good flexure resistance. Suitable for long distance, large volume and high-speed transportation of materials. The product is composed of core glue, wire rope, covering layer and edge glue.
Application: widely used in coal, mine, port, metallurgy, electric power, chemical industry and other fields to transport materials.
Varieties: according to the performance of the covering rubber can be divided into: ordinary type, flame retardant type, heat resistant type, wear-resistant type, cold-resistant type, acid and alkali resistant type, oil-resistant type and other varieties
Wire rope core conveyor belt to implement standards and main indicators
Varieties Standards and key indicators
Ordinary type GB/T9770-2001
Fire resistance type MT668-1997
General fire resistance type MT668-1997
Heat resistant type HG2297-92
Wear resistant type Shao boer Wear loss≦900mm³
Acid, alkali and oil resistant HG4-846
Hardy type brittleness temperature -40°C
Level code Tensile strength，Mpa≧ elongation at break %≧ Wear loss，mm³≦
D 18 400 90
H 25 450 120
L 20 400 150
P 14 350 200
Note:
D-Under strong wear working conditions；
H-Strong split under working conditions；
L-Under general working conditions；
P-Oil -, acid - and alkali - resistant, cold - resistant and generally inflammable conveyor belt
Baoxiang provides rubber belting for sale, we are committed to the alkaline resistant conveyor belt, material handling conveyor belt series, rich experience, welcome to consult.
Company Contact:
Contact Name: Hu Qiufang
Company Name: Hebei Taizhe Machinery Equipment Trading Co., Ltd.
Email:
Tel: 86031168026255
Fax: 860311-68026255
Street Address: Putian Building 12th
Floor, Botanical Garden Street
No.33, Xinhua District Shijiazhuang,
China. 050000 China
Website: https://www.hbtzmt.com
Member name: hbtzmt
Country:
China
Member Since: 25 January 2021
Total Leads: 15 hbtzmt Import Export Business Leads
Business focus: Dust Collector, Conveying System
Chat:
Verify: Safe Import Export Tips
