Top Cap Roll Forming Machine

Posted at: Offers to Sell and Export | Posted on: Wednesday 20 July 2016 8:08 am | Poster last visit: Monday 13 November 2017 |

Product Category: Main » Industrial Production and Manufacturing Services » Machining and processing services » Forming services » Roll forming services » Top Cap Roll Forming Machine


Product Photo:

cap roll forming machine

Similar Products Catalog:
Products Photos Catalog Cap Roll Forming Photos Catalog

Product Description:

Machine Name Glazed Tile Roll Forming Machine

Material Thickness 0.3-0.7mm


Coil width Custom-made,

1000mm or 1200mm or 1250mm

Yield Strength 250-300 Mpa

Material PPGI, Color Steel, GI.

Decoiler / Uncoiler Uncoiler Type Manual or Hydraulic or Auto Type

Coil Width Max. 1250mm

I.D 508-610mm

O.D Max. 1500mm

Glazed Tile Roll Forming Machine Forming Stations 13-18 Stations ( Depend on Profiles )

Roller material 45# steel, surface coated with 0.05mm hard chrome

Diameter of shaft 76mm

Shaft material High grade 45# steel

Drive type Chain transmission

Forming speed 0-15m/min

Main power 5.5KW

Pressing Device Pressing Type Hydraulic type pressing

Pressing Mould Cr12 Mov steel, HRC58-62

Cutting Device Cutting type Hydraulic cutting

Cutting Die Material Cr12Mov steel, HRC58-62

CuttingTolerance 10m+/-1.5mm

Encoder OMRON Brand

PLC Electrical Control Board PLC PANASONIC Brand

Inverter YASKAWA Brand

Touch screen PANASONICE

Operation type Touch screen & Button

Hydraulic Station Hydraulic station Famous Chinese brand

Hydraulic Power 5.5KW

Runout Tables Table type Simple nonpower type

Function To support the finished panels



Company Contact:

No member photo
Contact Name: Lemon
Company Name: Wuxi Techwell Machinery Co., Ltd
Email: Email
Tel: 86-158-61597732
Fax: 86-510-83133431
Street Address: Jingshi Road, Xibei
Town, Xishan District, Wuxi City,
Jiangsu Province, China Wuxi,
Jiangsu 214000 China
Other Contact Info:

Skype: Email
Whatsapp / Mob: 86-15861597732
Member name: LemonTechwellMachinery
Country: China-CN China
Member Since: 20 July 2016
Total Leads: 28 LemonTechwellMachinery Import Export Business Leads
Business focus: Roll Forming Machine, Slitting Cutting Machine, Insulated Sandwich Panel Machine
